Package -> Carton box -> Transparent plastic box Carton proofing machine DCH10 series

Main features: (1) Stable performance and low failure rate
(2) Steel belt transmission, accuracy guaranteed
(3) Low maintenance cost and easy operation
(4) Half-blade effect cuts perfectly

Product introduction

DCH10 series carton machine is mainly used for proofing and cutting applications of cardboard and plastic boxes. Good application in comparison to single and thin materials. Very suitable for low-cost proofing needs. Although the cutting material is relatively single, it has outstanding effects for specific industries. Comes with special knives, pressure rollers, pen tools, can cut indented cardboard, rubber sheet and other materials, in addition, the machine can also be used as a knife mold drawing. According to different cutting materials and application industries, it can also be called carton proofing machine, plastic box proofing machine, proofing machine, drawing cutting machine, etc.

Main cutting materials

Cardboard, PVC / PET film, stickers, greeting cards, tags, etc.

Technical Parameters

Model	DCH100906	DCH101209	DCH101512
Effective processing area	900*600mm	1200*900mm	1500*1200mm
Configuration	Knife: special tungsten steel knife / pen: ordinary signature pen, water-based ballpoint pen, oil-based ballpoint pen, pressure roller
Maximum speed	1000mm/s
Adsorption method	vacuum
Cutting method	Strokes, half-knife, full-knife, indentation
Cutting thickness	0.5-2mm
Minimum cutting circle diameter	Φ2mm
Repeat accuracy	≤0.1mm
Instruction system	International standards: HPGL or DXF
Transmission port	International Standard: Parallel / Serial
Machine operating language	Can be selected according to the area of use: Chinese, English, etc.
Voltage	220V±10% 50Hz，Local voltage and current can be selected according to the area of use
Fuse Specifications	5A
Land size (length * width * height)	1335*1065*1080mm	1635*1365*1080mm	1935*1665*1080mm
Remark	Other sizes can be customized
