KT Foam board cutting machine

Aoke computer prototype can complete the die-cutting, creasing, and forming of paper (plastic) products without the need for a knife mold or die-cutting machine, saving a lot of knife molds, die-cutting machines, and labor costs; In addition, if you are not satisfied with the box shape of the design, you can modify it at any time and make changes as needed. After confirming that the product meets the customer’s requirements, mass production can be carried out. This not only helps reduce production waste, but also helps your factory’s sales staff win customer orders and better serve customers. The materials cut by this product include cardboard, corrugated paper, thin wooden board, sponge, foam board, grey board paper, etc. The cutting area can be customized according to user needs. This system can completely replace manual design and sampling of cardboard boxes. The outstanding effect is that the designed products will be more scientific, reasonable, standardized, and reduce design and development time, freeing development and design personnel from tedious manual operations and allowing them to focus their maximum energy on product development.
Relevant parameters of KT board cutting and sampling machine:
Cutting area 1310 * 1000 1700 * 1300 2500 * 1600mm
Cutting materials: KT board, chiffon board, cardboard, corrugated paper, PVC plastic board, sponge, foam board. The maximum cutting thickness is 15mm
Positioning accuracy ≤ 0.025
Fixed method vacuum adsorption
Cutting accuracy ≤ 0.1mm
1、 2 interchangeable tool heads, integrated head frame for easy tool replacement.
2、 Four axis height motion controller, modular installation, easy to maintain.
3、 The cutting depth can be adjusted arbitrarily.
4、 The parameter settings are simple, and different materials can be processed by setting the thickness and speed.
Special knife: Cut card color, cowhide color, gray board color, PVC rubber plate, and adhesive color within 1.5mm.
60 degree knife: Cut card color and gray board color within 3mm.
26 degree knife: Cut corrugated paper within 5-7mm.
20 degree knife: Cut corrugated paper within 7-10mm.
16 degree knife: cutting corrugated paper within 10-15mm
The Aoke sampling machine is equipped with a wire pressing wheel
7mm pressure roller: suitable for corrugated paper within the range of 7-15mm.
5mm pressure roller: suitable for corrugated paper within the range of (5-7) mm.
3mm pressure roller: suitable for corrugated paper within a range of (3-5) mm.
2mm pressure wheel: suitable for corrugated paper, card color, cowhide color, gray board, rubber board, etc. within a range of 1.5mm.
Advanced and stable high-speed vibration cutting technology can accurately and quickly cut cardboard PVC、PET、 Materials such as grey cardboard, various types of corrugated paper, composite paper, honeycomb cardboard, etc;
